Abov MC97F60128 User Manual

200
MC97F60128
ABOV Semiconductor Co., Ltd.
T8DLYC (Timer 8 PWM C Delay Register : 6-ch PWM mode only) : 40A2H (XSFR)
7
6
5
4
3
2
1
0
T8DLYCA3
T8DLYCA2
T8DLYCA1
T8DLYCA0
T8DLYCB3
T8DLYCB2
T8DLYCB1
T8DLYCB0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
T8DLYCA[3:0]
PWM8CA Delay Data (Rising edge only)
T8DLYCB[3:0]
PWM8CB Delay Data (Rising edge only)
T8DR (Timer 8 Data Register: Timer and Capture mode only) : 40A3H (XSFR)
7
6
5
4
3
2
1
0
T8DR7
T8DR6
T8DR5
T8DR4
T4DR3
T8DR2
T8DR1
T8DR0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : FFH
T8DR[7:0]
T8 Data
T8CAPR (Timer 8 Capture Data Register: Read Case, Capture mode only) : 40A4H (XSFR)
7
6
5
4
3
2
1
0
T8CAPR7
T8CAPR6
T8CAPR5
T8CAPR4
T8CAPR3
T8CAPR2
T8CAPR1
T8CAPR0
R
R
R
R
R
R
R
R
Initial value : 00H
T8CAPR[7:0]
T8 Capture Data
T8CNT (Timer 8 Counter Register: Read Case, Timer mode only) : 40A5H (XSFR)
7
6
5
4
3
2
1
0
T8CNT7
T8CNT6
T8CNT5
T8CNT4
T8CNT3
T8CNT2
T8CNT1
T8CNT0
R
R
R
R
R
R
R
R
Initial value : 00H
T8CNT[7:0]
T8 Counter
