Port 5 is a bit-programmable I/O port which can be
configured as a schmitt-trigger input, a push-pull
output or an open-drain output.
A pull-up resistor can be specified in 1-bit unit.
Port 6 is a bit-programmable I/O port which can be
configured as a schmitt-trigger input, a push-pull
output or an open-drain output.
A pull-up resistor can be specified in 1-bit unit.
Port 7 is a bit-programmable I/O port which can be
configured as an input, a push-pull output or an open-
drain output.
A pull-up resistor can be specified in 1-bit unit.
Port 8 is a bit-programmable I/O port which can be
configured as an input, a push-pull output or an open-
drain output..
A pull-up resistor can be specified in 1-bit unit.
The P8 is not in the 64-Pin package.
Port 9 is a bit-programmable I/O port which can be
configured as a schmitt-trigger input, a push-pull
output or an open-drain output.
A pull-up resistor can be specified in 1-bit unit.
The P9 is not in the 64(MC97F67128LB14)/80-Pin
package.
The P91-P94 are not in the 64-Pin
(MC97F66128LB14) package.
Port A is a bit-programmable I/O port which can be
configured as a schmitt-trigger input, a push-pull
output or an open-drain output.
A pull-up resistor can be specified in 1-bit unit.
The PA is not in the 64(MC97F67128LB14)/80-Pin
package.
The PA2-PA4 are not in the 64Pin
(MC97F66128LB14) package.
Table 5-2 Normal Pin Description (Continued)
