Abov MC97F60128 User Manual

24
MC97F60128
ABOV Semiconductor Co., Ltd.
PIN
Name
I/O
Function
@RESET
Shared with
T0O
I/O
Timer 0 interval output
Input
P43/SEG32/EINT10/PWM0O
T1O
I/O
Timer 1 interval output
Input
P44/SEG33/EINT11/PWM1O
T2O
I/O
Timer 2 interval output
Input
P45/SEG34/EINT12/PWM2O
T3O
I/O
Timer 3 interval output
Input
P10/SEG58/EINT13/PWM3O/EXTSP2
T4O
I/O
Timer 4 interval output
Input
P11/SEG59/EINT14/PWM4O
T5O
I/O
Timer 5 interval output
Input
P12/SEG60/EINT15/PWM5O
T6O
I/O
Timer 6 interval output
Input
P13/SEG61/EINT16/PWM6O
T7O
I/O
Timer 7 interval output
Input
P62/AN8/EINT17
T8O
I/O
Timer 8 interval output
Input
P61/EINT18/PWM8AA
PWM0O
I/O
Timer 0 PWM output
Input
P43/SEG32/EINT10/T0O
PWM1O
I/O
Timer 1 PWM output
Input
P44/SEG33/EINT11/T1O
PWM2O
I/O
Timer 2 PWM output
Input
P45/SEG34/EINT12/T2O
PWM3O
I/O
Timer 3 PWM output
Input
P10/SEG58/EINT13/T3O/EXTSP2
PWM4O
I/O
Timer 4 PWM output
Input
P11/SEG59/EINT14/T4O
PWM5O
I/O
Timer 5 PWM output
Input
P12/SEG60/EINT15/T5O
PWM6O
I/O
Timer 6 PWM output
Input
P13/SEG61/EINT16/T6O
PWM8AA
I/O
Timer 8’s 6-ch PWM outputs
Input
P61/EINT18/T8O
PWM8AB
P60/SEG0
PWM8BA
P70/SEG1/VLC3
PWM8BB
P71/SEG2/VLC2
PWM8CA
P72/SEG3/VLC1
PWM8CB
P73/SEG4/VLC0
BLNK
I/O
External Sync Signal Input for 6-ch PWMs
Input
P00/AN0/EINT0
EC0-EC2
I/O
Timer 0/1/2 event count inputs
Input
P40-P42/SEG29-SEG31
EC3
I/O
Timer 3 event count input
Input
P26/COM6/SEG51/EXTSP0
EC4
I/O
Timer 4 event count input
Input
P27/COM7/SEG52/EXTSP1
EC5
I/O
Timer 5 event count input
Input
P14/SEG62/EINT8/DSCL
EC6
I/O
Timer 6 event count input
Input
P15/SEG63/EINT9/DSDA
EC7
I/O
Timer 7 event count input
Input
P63/AN9/DAC
SCK0
I/O
Serial 0 clock input/output
Input
P30/SEG37
SCK1
I/O
Serial 1 clock input/output
Input
P55/SEG23
SCK2
I/O
Serial 2 clock input/output
Input
P35/SEG42
SCK3
I/O
Serial 3 clock input/output
Input
P21/SEG46
MOSI0
I/O
Serial 0 data input/output
Input
P31/SEG38/TXD0/SDA0
MOSI1
I/O
Serial 1 data input/output
Input
P56/SEG24/TXD1/SDA1
MOSI2
I/O
Serial 2 data input/output
Input
P34/SEG41
MOSI3
I/O
Serial 3 data input/output
Input
P20/SEG45
MISO0
I/O
Serial 0 data input/output
Input
P32/SEG39/RXD0/SCL0
MISO1
I/O
Serial 1 data input/output
Input
P57/SEG25/RXD1/SCL1
MISO2
I/O
Serial 2 data input/output
Input
P33/SEG40/LDACB2
MISO3
I/O
Serial 3 data input/output
Input
P37/SEG44/LDACB3
Table 5-4 Normal Pin Description (Continued)
