USInST1 (USI0/1 Status Register 1: For UART and SPI mode) : 4038H/4048H (XSFR), n = 0 and 1
7
6
5
4
3
2
1
0
DREn
TXCn
RXCn
WAKEn
USInRST
DORn
FEn
PEn
R/W
R/W
R
R/W
R/W
R
R/W
R/W
Initial value : 80H
DREn
The DREn flag indicates if the transmit buffer (USInDR) is ready to receive new data. If
DREn is ‘1’, the buffer is empty and ready to be written. This flag can generate a DREn
interrupt.
0
Transmit buffer is not empty.
1
Transmit buffer is empty.
TXCn
This flag is set when the entire frame in the transmit shift register has been shifted out
and there is no new data currently present in the transmit buffer. This flag is
automatically cleared when the interrupt service routine of a TXCn interrupt is executed.
This flag can generate a TXCn interrupt. This bit is automatically cleared.
0
Transmission is ongoing.
1
Transmit buffer is empty and the data in transmit shift register are shifted out
completely.
RXCn
This flag is set when there are unread data in the receive buffer and cleared when all
the data in the receive buffer are read. The RXCn flag can be used to generate a RXCn
interrupt.
0
There is no data unread in the receive buffer
1
There are more than 1 data in the receive buffer
WAKEn
This flag is set when the RXDn pin is detected low while the CPU is in STOP mode. This
flag can be used to generate a WAKEn interrupt. This bit is set only when in
asynchronous mode of operation. This bit should be cleared by program software. (only
UART mode)
0
No WAKE interrupt is generated.
1
WAKE interrupt is generated
USInRST
This is an internal reset and only has effect on USIn. Writing ‘1’ to this bit initializes the
internal logic of USIn and this bit is automatically cleared to ‘0’.
0
No operation
1
Reset USIn
DORn
This bit is set if a Data OverRun occurs. While this bit is set, the
incoming data frame is ignored. This flag is valid until the receive buffer is read.
0
No Data OverRun
1
Data OverRun detected
FEn
This bit is set if the first stop bit of next character in the receive buffer is detected as ‘0’.
This bit is valid until the receive buffer is read. (only UART mode)
0
No Frame Error
1
Frame Error detected
PEn
This bit is set if the next character in the receive buffer has a Parity Error to be received
while Parity Checking is enabled. This bit is valid until the receive buffer is read. (only
UART mode)
0
No Parity Error
1
Parity Error detected
