Abov MC97F60128 User Manual

70
MC97F60128
ABOV Semiconductor Co., Ltd.
Address
Function
Symbol
R/W
@Reset
7
6
5
4
3
2
1
0
40C0H
D/A Converter Control Register
DACCR
R/W
0
0
0
0
0
0
0
0
40C1H
Programmable Gain Selection Register
PGSR
R/W
–
–
–
–
0
0
0
0
40C2H
D/A Converter Data Low Register
DACDRL
R/W
0
0
0
0
0
0
0
0
40C3H
D/A Converter Data High Register
DACDRH
R/W
0
0
0
0
0
0
0
0
40C4H
D/A Converter Buffer Low Register
DACBRL
R
0
0
0
0
0
0
0
0
40C5H
D/A Converter Buffer High Register
DACBRH
R
0
0
0
0
0
0
0
0
40C6H
Voice Prompt Control Register
VPCR
R/W
0
0
0
0
0
0
0
0
40C7H
Serial Flash Dummy and Data Number
SFDDNO
R/W
0
0
0
0
–
0
0
0
40C8H
D/A Converter Offset Control Register
DAOFSCR
R/W
0
0
–
–
0
0
0
0
40C9H
D/AC Interface Control Register
DACIFCR
R/W
0
–
0
0
0
0
0
0
40CAH
D/AC Interface Command Register
DACIFCMD
R/W
–
–
–
–
0
0
0
0
40CBH
Reserved
–
–
–
–
–
–
–
–
–
–
40CCH
Reserved
–
–
–
–
–
–
–
–
–
–
40CDH
Reserved
–
–
–
–
–
–
–
–
–
–
40CEH
Reserved
–
–
–
–
–
–
–
–
–
–
40CFH
Reserved
–
–
–
–
–
–
–
–
–
–
Table 8-13 Table 8.4 XSFR Map (Concluded)
