Abov MC97F60128 User Manual

79
MC97F60128
ABOV Semiconductor Co., Ltd.
Name
Address
Direction
Default
Description
P5
B0H
R/W
00H
P5 Data Register
P5IO
B9H
R/W
00H
P5 Direction Register
P5OD
4015H (XSFR)
R/W
00H
P5 Open-drain Selection Register
P5PU
EFH
R/W
00H
P5 Pull-up Resistor Selection Register
P5FSRH
4027H (XSFR)
R/W
00H
P5 Function Selection High Register
P5FSRL
4026H (XSFR)
R/W
00H
P5 Function Selection Low Register
P6
B8H
R/W
00H
P6 Data Register
P6IO
C1H
R/W
00H
P6 Direction Register
P6OD
4016H (XSFR)
R/W
00H
P6 Open-drain Selection Register
P6PU
A6H
R/W
00H
P6 Pull-up Resistor Selection Register
P6FSRH
4029H (XSFR)
R/W
00H
P6 Function Selection High Register
P6FSRL
4028H (XSFR)
R/W
00H
P6 Function Selection Low Register
P7
C0H
R/W
00H
P7 Data Register
P7IO
C9H
R/W
00H
P7 Direction Register
P7OD
4017H (XSFR)
R/W
00H
P7 Open-drain Selection Register
P7PU
A7H
R/W
00H
P7 Pull-up Resistor Selection Register
P7FSRH
402BH (XSFR)
R/W
00H
P7 Function Selection High Register
P7FSRL
402AH (XSFR)
R/W
00H
P7 Function Selection Low Register
P8
99H
R/W
00H
P8 Data Register
P8IO
D1H
R/W
00H
P8 Direction Register
P8OD
4018H (XSFR)
R/W
00H
P8 Open-drain Selection Register
P8PU
ADH
R/W
00H
P8 Pull-up Resistor Selection Register
P8FSR
402CH (XSFR)
R/W
00H
P8 Function Selection Register
P9
A1H
R/W
00H
P9 Data Register
P9IO
D9H
R/W
00H
P9 Direction Register
P9OD
4019H (XSFR)
R/W
00H
P9 Open-drain Selection Register
P9PU
AEH
R/W
00H
P9 Pull-up Resistor Selection Register
P9DB
CFH
R/W
00H
P9 Debounce Enable Register
P9FSR
402DH (XSFR)
R/W
00H
P9 Function Selection Register
PA
A3H
R/W
00H
PA Data Register
PAIO
E1H
R/W
00H
PA Direction Register
PAOD
401AH (XSFR)
R/W
00H
PA Open-drain Selection Register
PAPU
AFH
R/W
00H
PA Pull-up Resistor Selection Register
PADB
D7H
R/W
00H
PA Debounce Enable Register
PAFSR
402EH (XSFR)
R/W
00H
PA Function Selection Register
PB
A4H
R/W
00H
PB Data Register
PBIO
E9H
R/W
00H
PB Direction Register
PBOD
401BH (XSFR)
R/W
00H
PB Open-drain Selection Register
PBPU
B6H
R/W
00H
PB Pull-up Resistor Selection Register
PBFSR
402FH (XSFR)
R/W
00H
PB Function Selection Register
PD
A5H
R/W
00H
PD Data Register
PDIO
F1H
R/W
00H
PD Direction Register
PDOD
401CH (XSFR)
R/W
00H
PD Open-drain Selection Register
PDPU
B7H
R/W
00H
PD Pull-up Resistor Selection Register
PDFSR
4037H (XSFR)
R/W
00H
PD Function Selection Register
Table 9-2 Port Register Map
