Agilent Technologies 1100 Series Reference Manual

Repairing the Fluorescence Detector 5
1100 Series FD Reference Manual 167
5
Use a flat screw driver to lift the leak base from the base. 6 Remove the leak base completely.
7 Replace the leak pan into the cabinet bottom. Press the
leak pan completely down into its recess.
8 Replace the leak sensor using your left hand and
reconnect the connector.
Next Steps:
• Replace the covers as described in “Replacing the Foams and Covers" on page 196.
• Re-install the flow cell and the front panel
• Re-install the detector in the stack.
B
B
B
