Agilent Technologies 1100 Series - Page 171

Repairing the Fluorescence Detector 5
1100 Series FD Reference Manual 173
2
Carefully remove the front foam holding the foam as
shown.
3 Remove the UV protector.
4 Locate the mirror assembly. 5 Use a pair of tweezers to lift off the top of the mirror
holder.
