5 Repairing the Fluorescence Detector
6
Remove the mirror assembly. 7 Insert the new mirror into the holder. The mirror surface
faces towards the light. The back side is marked as
shown.
Note:
If the mirror is inserted in the opposite direction, the detector cannot be aligned correctly.
8
Replace the mirror assembly and lock the top over the pin. 9 Replace the UV protector.
Mirror surface faces
to this side!
R
