272 Chapter5
Language Reference
SENSe Subsystem
Define the custom set of offset frequencies at which the switching
transient spectrum part of the ACP measurement will be made. The list
contains five (5) entries for offset frequencies. Each offset frequency in
the list corresponds to a resolution bandwidth in the bandwidth list.
An offset frequency of zero turns the display of the measurement for
that offset off, but the measurement is still made and reported. You can
turn off (not use) specific offsets with the
[:SENSe]:ACP:OFFSet:LIST:STATe command.
Offset[n] n=1 is base station and 2 is mobiles. The default is base
station (1).
List[n]
cdmaOne mode n=1 is cellular bands and 2 is pcs bands. The default is
cellular.
W-CDMA (Trial
& Arib) mode n=1 is ARIB, 2 is 3GPP, and 3 is Trial. The default is
ARIB (1).
Factory Preset
and *RST:
Mode Variant Offset A Offset B Offset C Offset D Offset E
iDEN 25 kHz n/a n/a n/a n/a
Basic 750 kHz 1.98 MHz 0 Hz 0 Hz 0 Hz
cdmaOne BS cellular 750 kHz 1.98 MHz 0 Hz 0 Hz 0 Hz
BS pcs 885 kHz 1.25625
MHz
2.75 MHz 0 Hz 0 Hz
MS cellular 885 kHz 1.98 MHz 0 Hz 0 Hz 0 Hz
MS pcs 885 kHz 1.25625
MHz
2.75 MHz 0 Hz 0 Hz
cdma2000 BTS 750 kHz 1.98 MHz 0 Hz 0 Hz 0 Hz
MS 885 kHz 1.98 MHz 0 Hz 0 Hz 0 Hz
W-CDMA
(3GPP)
5 MHz 10 MHz 15 MHz 20 MHz 25 MHz
W-CDMA (Trial
& Arib)
5 MHz 10 MHz 15 MHz 20 MHz 25 MHz
