218 Chapter5
Language Reference
DISPlay Subsystem
Waveform - Y-Axis Reference Level
:DISPlay:WAVeform[n]:WINDow[m]:TRACe:Y[:SCALe]:RLEVel
<power>
:DISPlay:WAVeform[n]:WINDow[m]:TRACe:Y[:SCALe]:RLEVel?
Sets the amplitude reference level for the y-axis.
n, selects the view, the default is RF envelope.
n=1, RF envelope
n=2, I/Q waveform
m, selects the window within the view. The default is 1.
Factory Preset
and *RST: 0 dBm, for RF envelope
Range: −250 to 250 dBm, for RF envelope
Default Unit: dBm, for RF envelope
Remarks: May affect input attenuator setting.
To use this command, the appropriate mode should be
selected with INSTrument:SELect.
Front Panel
Access: When in Waveform measurement:
Amplitude Y Scale,
Ref Level
SPECtrum - (frequency domain)
(all modes)
RFENvelope (n=2)
a
for Service mode
IQ (n=3)
a
SPECtrum (n=4)
a
ASPectrum (n=7)
a
yes
WAVEform - (time domain)
(all modes)
RFENvelope (n=2)
a
IQ (n=8)
a
yes
a. The n number indicates the sub-opcode that corresponds to this
trace. Detailed descriptions of the trace data can be found in the
MEASure subsystem documentation by looking up the
sub-opcode for the appropriate measurement.
Measurement Available Traces
Markers
Available?
To Next Page
