Agilent Technologies E4406A VSA Series User Manual

194 Chapter5
Language Reference
CALCulate Subsystem
PVTime - power versus time
(GSM, Service modes)
RFENvelope (n=2)
a
UMASk (n=3)
a
LMASk (n=4)
a
yes
RHO - modulation quality
(cdmaOne, cdma2000, W-CDMA
(3GPP), W-CDMA (Trial & Arib)
modes)
EVM (n=2)
a
MERRor (n=3)
a
PERRor (n=4)
a
yes
SEMask - spectrum emissions mask
(cdma2000, W-CDMA (3GPP) mode)
SPECtrum (n=0)
a
yes
TSPur - transmit band spurs
(GSM mode)
SPECtrum (n=2)
a
ULIMit (n=3)
a
yes
TXPower - transmit power
(GSM mode)
RFENvelope (n=2)
a
IQ (n=8)
a
yes
SPECtrum - (frequency domain)
(all modes)
RFENvelope (n=2)
a
for Service mode
IQ (n=3)
a
SPECtrum (n=4)
a
ASPectrum (n=7)
a
yes
WAVEform - (time domain)
(all modes)
RFENvelope (n=2)
a
IQ (n=8)
a
yes
a. The n number indicates the sub-opcode that corresponds to this
trace. Detailed descriptions of the trace data can be found in the
MEASure subsystem documentation by looking up the
sub-opcode for the appropriate measurement.
Measurement Available Traces
Markers
Available?
