Chapter 5 193
Language Reference
CALCulate Subsystem
EORFspectr - EDGE output RF
spectrum
(EDGE mode)
RFEModulation
(n=2)
a
RFESwitching
(n=3)
a
yes, only for
a single
offset
EPVTime - EDGE power versus time
(EDGE mode)
RFENvelope (n=2)
a
UMASk (n=3)
a
LMASk (n=4)
a
yes
EVM - error vector magnitude
(NADC, PDC modes)
EVM (n=2)
a
MERRor (n=3)
a
PERRor (n=4)
a
yes
EVMQpsk - QPSK error vector
magnitude
(cdma2000, W-CDMA (3GPP),
W-CDMA (Trial & Arib) modes)
EVM (n=2)
a
MERRor (n=3)
a
PERRor (n=4)
a
yes
IM - intermodulation
(cdma2000, W-CDMA (3GPP) modes)
SPECtrum (n=0)
a
yes
MCPower - multi-carrier power
(W-CDMA (3GPP) mode)
no traces
no markers
OBW - occupied bandwidth
(cdmaOne, cdma2000, iDEN, PDC,
W-CDMA (3GPP) modes)
no traces
no markers
ORFSpectrum - output RF spectrum
(GSM mode)
RFEModulation
(n=2)
a
RFESwitching
(n=3)
a
yes, only for
a single
offset
PFERror - phase and frequency error
(GSM mode)
PERRor (n=2)
a
PFERror (n=3)
a
RFENvelope (n=4)
a
yes
PSTatistic - power statistics CCDF
(Basic, cdma2000, W-CDMA (3GPP),
W-CDMA (Trial & Arib) modes)
MEASured (n=2)
a
GAUSian (n=3)
a
REFerence (n=4)
a
yes
Measurement Available Traces
Markers
Available?
