Chapter 5 277
Language Reference
SENSe Subsystem
W-CDMA (Trial
& Arib) mode n=1 is ARIB, 2 is 3GPP, and 3 is Trial. The default is
ARIB (1).
Factory Preset
and *RST:
Range: −150.0 dB to 50.0 dB for cdmaOne, cdma2000,
W-CDMA (3GPP), W-CDMA (Trial & Arib), Basic
−200.0 dB to 50.0 dB for iDEN
Default Unit: dB
Remarks: You must be in Basic, cdmaOne, cdma2000, W-CDMA
(3GPP), W-CDMA (Trial & Arib), or iDEN mode to use
this command. Use INSTrument:SELect to set the
mode.
Mode Variant Offset A Offset B Offset C Offset D Offset E
iDEN 0 dBc n/a n/a n/a n/a
Basic −45 dBc −60 dBc 0 dBc 0 dBc 0 dBc
cdmaOne BS cellular −45 dBc −60 dBc 0 dBc 0 dBc 0 dBc
BS pcs −45 dBc 0 dBc 0 dBc 0 dBc 0 dBc
MS cellular −42 dBc −54 dBc 0 dBc 0 dBc 0 dBc
MS pcs −42 dBc 0 dBc 0 dBc 0 dBc 0 dBc
cdma2000 0 dBc 0 dBc 0 dBc 0 dBc 0 dBc
W-CDMA
(3GPP)
0 dBc 0 dBc 0 dBc 0 dBc 0 dBc
W-CDMA (Trial
& Arib)
0 dBc 0 dBc 0 dBc 0 dBc 0 dBc
