42 Chapter1
Preparing for Use
Programming the Transmitter Tester
EDGE w/GSM - Option 202
or
EDGE w/GSM - Option 252
INST:SELECT EDGEGSM
• ORFSpectrum - output RF spectrum measurement
• PFERror - phase and frequency error measurement
• PVTime - power versus time measurement
• TXSPurs - transmit band spurs measurement
• EEVM - EDGE error vector magnitude measurement
• EPVTime - EDGE power versus time measurement
• EORFspectr - EDGE output RF spectrum measurement
• SPECtrum - spectrum (frequency domain) measurement
• TXPower - transmit power measurement
• WAVeform - waveform (time domain) measurement
GSM - Option BAH
INST:SELECT GSM
• ORFSpectrum - output RF spectrum measurement
• PFERror - phase and frequency error measurement
• PVTime - power versus time measurement
• TXSPurs - transmit band spurs measurement
• SPECtrum - spectrum (frequency domain) measurement
• TXPower - transmit power measurement
• WAVeform - waveform (time domain) measurement
NADC - Option BAE
INST:SELECT NADC
or
PDC - Option BAE
INST:SELECT PDC
• ACP - adjacent channel power measurement
• EVM - error vector magnitude measurement
• OBWidth - occupied bandwidth measurement
• SPECtrum - spectrum (frequency domain) Measurement
• WAVeform - waveform (time domain) measurement
iDEN - Option HN1
INST:SELECT IDEN
• ACP - adjacent channel power measurement
• BER - bit error rate measurement
• OBWidth - occupied bandwidth measurement
• SPECtrum - spectrum (frequency domain) Measurement
• WAVeform - waveform (time domain) measurement
Table 1-1 Available Modes and Measurements
Modes Measurement Keywords
