Benelli TRK 502 Service Station Manual

2 - 4
ENGINE SPECIFICATIONS
ENGINE STANDARD
Type of engine 4 stroke, 2 cylinders in line,
liquid cooling, 8 valves
Cubic capacity
499.6 cc
Number of cylinders 2
Cylinder layout
In line
Inside diameter × stroke
69x66.8 mm
Compression ratio
11.5:1
Idle speed
1400
Idle speed
1600
Distribution Double overhead camshaft, chain-con-
trolled, and four-valves for each cylinder
Maximum net power
28 kW/1100 rpm (38.06 hp)
Maximum net torque
52 N.m/10500 rpm
FUEL
STANDARD
Recommended fuel premium unleaded petrol RON 95 min
ENGINE OIL STANDARD
Forced lubrication system with wet sump design
Total amount 3.2 l
Quantity without oil fi lter cartridge re-
placement
3 l
Quantity with oil fi lter cartridge replace-
ment
3.2 l
Recommended oil
API SH 15W50 (synthetic)
Jaso -MACCMC g4
10W50
OIL FILTER STANDARD
Type of oil fi lter Cartridge
OIL PUMP STANDARD
Oil pump type lobe
Clearance between inner rotor tip and
rotor tip
0.25 mm max
Clearance between outer rotor tip and oil
pump housing
0.2 mm max
STARTING STANDARD
Starting system type electrical
TECHNICAL DATA
COPY - Moto GB - Grant Martland - grantmartland@motogb.co.uk

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
