ELE. - 27
IDROSTOP
O
It is a switch situated on the rear brake pump, which reads the
oil pressure exerted on the pump.
It serves to switch the stop lights on (A), Fig. O.
Check:
• The continuity
by positioning the multitester on PIN 1 and PIN 2 and checking
the table.
BRAKE PIN 1 PIN 2
Pulled
• •
Released
• •
NOTE:________________________________
When the above conditions are fullled, the front brake sen-
sor is working properly, otherwise replace the part.
