Benelli TRK 502 Service Station Manual

ELE. - 59
VEHICLE BATTERY
BATTERY
1
IMPORTANT NOTICE
Do not use batteries other than the indicated ones (A), Fig. 1.
The MF battery (maintenance-free) mounted on this vehicle
does not require maintenance operations, as electrolyte level
control and topping up of distilled water.
Please note that the charging system of the MF battery differs
from the one of a standard one.
Therefore, do not replace the MF battery with a standard one.
The recommended battery is 12V-9Ah.
IMPORTANT NOTICE
Hydrogen is not produced during the normal recharge of the
battery, but it can be produced when the battery is recharged
excessively.
Pleasekeepamesawayfrombatteryduringrecharge.
In case of corroded terminals, remove the battery, pour warm
water on it and clean using a metal brush.
At the end of connection, grease slightly.
Mount a cap on the positive terminal.
A
COPY - Moto GB - Grant Martland - grantmartland@motogb.co.uk

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
