5 - 33
PISTONS
1
1
2
2
2
3
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
5
9
Pos. Description Qty. SQ. SYMBOLS
INTERVENTION
DESCRIPTION
REMARKS
1 PISTON SEGMENT SERIES
2 PIN RETAINING RING
3 PISTON PIN
4 PISTON
5 COMPLETE CONNECTION ROD
6 PLUG
7 SCREW
8 GUIDE BUSHING
9 CONNECTING ROD MAIN BEARING SHELL
10 COUNTERSHAFT
11 NUT
12 WASHER
13 FULL DRIVE SHAFT
14 SPLINE
15 PLUG
16 GEAR
17 DRIVE SHAFT GEAR
