Benelli TRK 502 Service Station Manual

5 - 88
POWER SYSTEM
21
4
1
2
3
5
6
7
8
9
9
11
10
12
12
13
15
14
16
18
19
20
51
22
23
23
24
25
26
27
5
28
29
30
31
31
32
33
34
35
36
38
37
39
38
40
41
42
43
44
14
14
45
45
46
38
40
47
48
15
48
15
35
49
50
49
50
17
52
Pos. Description Qty. SQ. SYMBOLS
INTERVENTION
DESCRIPTION
REMARKS
1
NUT
2 SCRAPING
3 FLANGE
4 WASHER
5 WASHER
6 OIL SEAL
7 SHAFT
8 THROTTLE VALVE FLANGE
9 SCREW
10 BUSHING
11 SPRING
12 SCREW
13 BRACKET
14 STEERING RING NUT
15 SCREW
16 INSERT
17 CAP
18 INJECTOR
19 BRACKET
20 MAP SENSOR
21 SCREW
22 PIPE
23 PIPE GLAND CLIP
24 INSERT
THROTTLE BODY
COPY - Moto GB - Grant Martland - grantmartland@motogb.co.uk

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
