HOW TO USE THIS MANUAL
This manual is a practical reference guide that is easy for mechanics to handle and use. The explanations of all of the installation,
removal, disassembly, installation, repair and inspection procedures are organised into sequences of individual steps.
1. Each chapter is divided into sections. The title of the current section will be found at the top of every page.
2. To help with the identi cation of plants and make the different points of the various procedures clearer, the start of each section
about the removal or disassembly of parts will contain exploded drawings.
3. The parts to be lubricated or replaced are marked with symbols. See the section entitled “SYMBOLS”.
4. The exploded drawing is accompanied by a table with the instructions for the intervention, stating the order of operations, the
name of the parts, any notes about the job, etc.
5. Interventions requiring additional information (for example, special tools and technical information) will be described in se-
quence.
