Benelli TRK 502 Service Station Manual

ELE. - 41
ERROR TABLE
Code error Error description
514 2nd injector - open circuit
612 2nd injector - short circuit to ground
613 2nd injector - positive short circuit
801 Drive shaft position sensor - failure (out of range)
802 Drive shaft position sensor - failure (open circuit)
1092 Vapour exhaust checking valve - open circuit
1112 Vapour exhaust checking valve - too low circuit voltage
1113 Vapour exhaust checking valve - too high circuit voltage
1281 Speed sensor - failure (out of range)
1286 High minimum speed target compared to the limit of air control system
1287 Low minimum speed target compared to the limit of air control system
1288 IAC (idle air control) - short circuit to ground
1289 IAC (idle air control) - positive short circuit
1297 IAC (idle air control) - open circuit
1376 Abnormal system voltage response (out of range)
1378 Too low system voltage
1379 Too high system voltage
1538 ECU map - coding error
1575 Fuel pump relay check - open circuit
1576 Fuel pump relay check - short circuit to ground
1577 Fuel pump relay check - positive short circuit
1616 Lamp circuit error - MIL indication
8567 Too high CLL value
8558 Too low CLL value
4375 Canister purge valve - positive short circuit
4374 Too high engine temperature
4375 Canister purge valve - short circuit to ground
4376 Canister purge valve - open circuit
1393 Brake switch - failure
4406 K line - open circuit
DEVICES
INJECTION ECU
COPY - Moto GB - Grant Martland - grantmartland@motogb.co.uk

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
