CHAPTER 5 PERIODIC MAINTENANCE
5-16
(7) Mount the rear cover C using the bind B M4x12 Taptite screw.
Fig.5-24
(8) Insert the paper tray.
Fig.5-25
Taptite, bind B M4x12
Front cover ASSY
Paper Tray
Rear cover C
