Brother MFC-9330CDW Service Manual

2-19
Confidential
7801 ---
7802 ---
7900 After the manual feed sensor
detects pass of paper fed from
the manual feed slot, the
registration rear sensor does not
detect paper pass after a set
period of time. Or after the
manual feed sensor detects
paper pass, the registration rear
sensor detects paper
pass within a set period of time.
2-60
7C00 ---
7D00 ---
7E00 ---
8401 ---
8402 ---
8501 The paper feed sensor detected
that the paper tray was not set
(
before print registration in
engine) in 2-sided printing.
2-61
8502 ---
8503 ---
8504 ---
8505 The paper feed sensor detected
that the paper tray was not set
(after print registration in engine)
in 2-sided printing.
2-61
8506 ---
8507 ---
8508 ---
8601 ---
8602 ---
8603 ---
8604 ---
8701 ---
8702 ---
8703 ---
Error
codes
Problem
Refer
to:
8604 ---
8701 ---
8702 ---
8703 ---
8801 ---
8802 ---
8901 ---
8902 ---
8903 The back cover sensor detected
the open state when 2-sided
printing is started (before the
registration of printing in the
engine).
2-61
8904 The back cover sensor detected
the open state during 2-sided
printing (after the registration of
printing in the engine).
2-61
8A01 The registration rear sensor
detected that the fed paper was
larger or smaller than the
specified size in 2-sided printing.
2-62
8A02 ---
8C00 No paper is in the manual feed
slot when printing from the
manual feed slot.
2-62
8D01 The registration rear sensor
detected that the paper loaded in
the paper tray was smaller than
the specified size.
2-63
8D02 When printing with the back
cover closed, the paper size
selected in the print data is
smaller than the valid size.
2-63
8E01 Upon fax reception, the paper
size setting is the one other than
A4, Letter, Legal, and Folio.
2-63
Error
codes
Problem
Refer
to:

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
