Brother MFC-9330CDW Service Manual

2-21
Confidential
9804 Error occurred with the value
measured during density sensor
sensitivity calibration.
2-67
9901 Error occurred with the value
measured during adjustment of
color registration.
2-68
9902 Dot counter or develop roller
counter of color toner has
reached the upper limit during
adjustment of color registration.
2-68
9903 Error occurred during patch data
printing in adjustment of color
registration.
2-69
9A01 Error occurred with the value
measured during auto color
registration performed from the
control panel.
2-70
9A02 Dot counter or develop roller
counter of color toner has
reached the upper limit during
auto color registration
performed from the control
panel.
2-70
9A03 Error occurred during patch data
printing in auto color registration
performed from the control panel.
2-71
9A04 ---
9C01 ---
9C02 ---
9C03 ---
9C06 ---
9C07 ---
A000 Upon scanning the second side
in duplex scanning, scanned
data cannot be output with the
required number of pixels and
image processing is not
completed successfully.
2-71
Error
codes
Problem
Refer
to:
A200 During document scanning, the
first side document scanning
position sensor detected that the
document length was 90 cm or
more.
2-72
A300 Though a document was fed and
conveyed by the specified
distance or longer, the first side
document scanning position
sensor did not detect the passing
of the paper.
2-72
A400 The ADF cover sensor detected
that the ADF cover was opened.
2-72
A500 Upon scanning a fax, the first
side CIS white or black
calibration data was not within
the normal range.
2-73
A600 Though a fax was scanned again
after A500 error, the first side
CIS white or black calibration
data was not within the normal
range.
2-73
A700 The ROM color parameter does
not match the first side CIS or
second side CIS.
2-73
A800
When an image was scanned
and processed, an error was
detected in ROM color parameter.
2-73
A900 When an image was scanned
and processed, a scanning error
occurred.
2-73
AA00 ---
AB00 ---
AC00 Upon scanning a fax, the second
side white or black calibration
data was not within the normal
range.
2-73
Error
codes
Problem
Refer
to:

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
