Auxiliary functions
*
OK
*
OK
Input value
Deviation:
Input value
Limit:
SELEC
SELEC
ENTER
EXIT
EXIT
ENTER
SELEC
Tolerance for the
permitted control
deviation
Adjustment range:
1 ... 50 %**
Input the limit
position
Adjustment range:
0 ... 100 %
Selection of the
switching state
Alarm output for exceeding the permitted control
deviation
Output: current position with respect to a specified limit
position
Output: Actuator in safety position
Output: Sensor break
for process set-point value/set-point position ***
Only available if activated in the SIG.ERR menu
(SIG.ERR → SP/CMD Input → Error on)
Output: Sensor break for process actual value
Only available if activated in the SIG.ERR menu
(SIG.ERR → PV Input → Error on)
Output: Operating state MANUAL / AUTOMATIC
Output: X.TUNE status
Output: Diagnosis message (option)
Setting switching status (NC / NO)
EXIT
SELEC
FAILURE
OUT SPEC.
FUNC.CHECK
MAINTENANCE
Error
Outside the
specification
Function check
Maintenance required
OUT BIN1
OUT BIN2
POS.Dev
POS.Lim-1/2
Safepos
ERR.SP/CMD
ERR.PV
Only for type 8793:
Remote
Tune.Status
DIAG.State -1/2
OUT.type
normally open
normally closed
* If the submenu is left by pressing the
ESC
key, the value remains unchanged.
** The permitted control deviation Lim DEV.X XX must not be less than the dead band.
*** The function refers to the respective set-point value. Positioner = CMD; process controller = SP
Figure 75: Operating structure OUTPUT-BIN1/BIN2
