Auxiliary functions
26.2.15.1. Calibration of the position actual value and the position set-
point value
Key Action Description
MENU
Press for approx. 3 s
Switching from process level setting level.
/ Select CAL.USER (To do this, the auxiliary function must be incorporated into the main
menu).
ENTER
The submenu options are displayed.
calibr. POS - Calibration of the position actual value (0 - 100 %):
/ Select calibr.POS
ENTER
Press
The menu options for the minimum and the maximum position actual
values are displayed.
/ Select POS. pMin
INPUT
Press
The input screen for the lower value (POS.lower) is opened.
/
OPN
Open more
CLS
Close more
Approach minimum position of the valve.
OK
Press
Transfer and simultaneous return to the calibr.POS menu.
/ Select POS. pMax
INPUT
Press
The input screen for the upper value (POS.upper) is opened.
/
OPN
Open more
CLS
Close more
Approach maximum position of the valve.
OK
Press
Transfer and simultaneous return to the calibr.POS menu.
EXIT
Press
Acknowledgment and simultaneous return to the CAL.USER menu.
calibr. INP calibration of the position set-point value (4 ... 20 mA; 0 ... 20 mA; 0 ... 5 V, 0 ... 10 V):
/ Select calibr.INP
ENTER
Press
The menu options for the minimum and maximum value of the input
signal are displayed.
/ Select INP 0mA (4mA/0V) The minimum value for the input signal is displayed.
- - Apply the minimum value to the input.
OK
Press
Transfer and simultaneous return to the calibr.INP menu.
/ Select INP 20mA (5V/10V) The maximum value for the input signal is displayed.
- - Apply the maximum value to the input.
OK
Press
Transfer and simultaneous return to the calibr.INP menu.
EXIT
Press
Acknowledgment and simultaneous return to the CAL.USER menu.
EXIT
Press
Acknowledgment and simultaneous return to the main menu (MAIN).
EXIT
Press
Switching from setting level process level.
Table 65: CAL.USER; calibration of position actual value and position set-point value
