Canon imagePROGRAF IPF720 User Manual

Canceling print jobs
Canceling Print Jobs from W indows
Y ou can cancel print jobs in the printer window .
1. Click the printer icon in the taskbar to display the printer window .
Note
• Y ou can also display this window by double-clicking the printer icon in the Printers and Faxes (or
Printers ) folder , accessible through the Windows start menu.
2. Right-click the job to cancel and select Cancel .
Note
• The print job is displayed on the printer screen during the transmission of print data from the
computer . When the transmission is nished, the job is not displayed even during printing.
T o cancel print jobs from the Control Panel , follow these steps.
1. If the Display Screen of the Control Panel still indicates that the job is in progress and the Data
lamp continues ashing, hold down the Stop button for a second or more to stop printing.
Do the following if no print jobs are shown in the printer window (because they have already been sent to
the printer).
1. Double-click the taskbar icon to access the imagePROGRAF Status Monitor .
2. On the Printer Status sheet, click Cancel Job .
Basic Printing W orkow 93

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
