Canon imagePROGRAF IPF720 User Manual

Printer Driver
Media Detailed Settings Dialog Box (Mac OS X)
The Paper Detailed Settings dialog box of fers the following settings. For details on settings items, refer to
the printer driver help.
Note
• T o display the Paper Detailed Settings dialog box, on the Main pane, click Settings by Media
T ype . ( → P .387)
Setting Item
Description
A Media T ype
Select the paper type.
For information on the types of paper the printer supports, refer to the Paper
Reference Guide . ( → P .96)
B Drying T ime Specify the time that the printer waits for ink to dry , as needed. The Drying
T ime setting is only valid for rolls.
( → P .120)
C Between Pages
Specify the time the printer waits after printing a page until ejecting the
paper , as needed.
D Between Scans Specify the time the printer waits after printing a line on the page until
printing the next line, as needed.
E Roll Paper Margin for
Safety
Y ou can specify the length of a margin on the leading edge of paper to
ensure that paper susceptible to curling is held rmly against the Platen .
F Near End Margin Specify the length of the Near End Margin (the leading edge margin) of the
roll, as needed.
G Cut Speed
Select the speed of automatic cutting, as needed. Y ou can adjust this setting
if paper is not cut well when automatic cutting is used.
H Automatic Cutting Y ou can activate or deactivate Automatic Cutting and printing of cut lines,
as desired. In this list, specify Y es , No , or Print Cut Guideline .
J Mirror Specify whether to print a mirror image, as needed. Select this option to print
a version of the document or image with the left and right sides inverted.
390 Mac OS X Software

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
