Canon imagePROGRAF IPF720 User Manual

Printer Driver
W indows Software
Printer Driver
Printer Driver Settings (W indows)
For instructions on accessing the Windows printer driver , refer to the following topics.
• Accessing the Printer Driver Dialog Box from Applications (Windows) (→P .343)
• Accessing the Printer Driver Dialog Box from the Operating System Menu (Windows) (→P .345)
For information on the Windows printer driver settings, refer to the following topics.
• Main Sheet (Windows) (→P .347)
Y ou can specify the type of paper , color processing, print quality , print preview , and other settings.
Choose Easy Settings to specify basic print settings based on the printing application or Advanced
Settings to complete more detailed settings as desired.
• Media Detailed Settings Dialog Box (Windows) (→P .351)
• V iew Settings Dialog Box for the Printing Application (Windows) (→P .352)
• Color Adjustment Sheet: Color (Windows) (→P .353)
• Matching Sheet (Windows) (→P .355)
• Color Adjustment Sheet: Monochrome (Windows) (→P .357)
• Page Setup Sheet (Windows) (→P .359)
Y ou can specify the page size of the original, borderless printing, enlargement or reduction, the
orientation, the paper size and feed source, and automatic cutting.
• Paper Size Options Dialog Box (Windows) (→P .361)
• Layout Sheet (Windows) (→P .362)
Y ou can specify the page layout, watermarks, the orientation, the number of copies, and print processing
options.
• Page Options Dialog Box (Windows) (→P .364)
• Special Settings Dialog Box (Windows) (→P .365)
• Favorites Sheet (Windows) (→P .366)
Groups of print settings you select on each sheet can be saved as a favorite. Favorites you have added
can be edited or used at the time of printing as desired.
Windows Software 333

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
