Optional accessories
Optional accessories
Roll Holder Set
A set of parts comprising the Roll Holder , Holder Stopper , 2-Inch Paper Core Attachment , and 3-Inch Paper
Core Attachment .
T o load a roll with a 3-inch paper core, remove the 2-Inch Paper Core Attachment from the Holder Stopper
and then attach the 3-Inch Paper Core Attachment on both the Roll Holder and Holder Stopper .
T o load a roll with a 2-inch paper core, remove the 3-Inch Paper Core Attachment from both the Roll Holder
and Holder Stopper and then attach the 2-Inch Paper Core Attachment on the Holder Stopper . ( → P .129)
• Roll Holder Set RH4-32 (for 2- and 3-inch paper cores)
IEEE 1394 (FireW ire) Expansion Board
An interface board to add an IEEE 1394 (also called "FireWire") port.
• IEEE1394 Expansion Board EB-05
Caution
• Note that EB-04 is incompatible.
For instructions on installing the IEEE 1394 expansion board, refer to the documentation provided with the
optional IEEE 1394 expansion board.
Printer Parts 73

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
