Canon imagePROGRAF IPF720 User Manual

Messages regarding printing or adjusment
Messages regarding printing or adjusment
Use another paper .
Cause Corrective Action
W e recommend using a type of paper that you often
use, other than lm, for Printhead adjustment.
( → P .491)
The Printhead and feed amount cannot be adjusted
when highly transparent lm is loaded.
Adjust the feed amount manually .
( → P .501)
Cannot print as specied.
Lift the release lever and replace paper with A4/L TR (vertical) or larger
Cause Corrective Action
The loaded paper is too small. Switch to paper A4/Letter (vertical) or larger .
Lift the release lever and replace roll with 10 in. wide or larger roll
Cause Corrective Action
The loaded paper is too small. Load a roll 10 inches wide or larger .
Cannot adjust band.
Cause Corrective Action
The Printhead nozzles are clogged. Follow the steps below to check the nozzles.
1. Print a test pattern to check the nozzles.
( → P .516)
2. Clean the Printhead if the nozzles are clogged.
( → P .517)
Highly transparent lm is loaded that cannot be used
for feed amount adjustment.
Adjust the feed amount manually .
( → P .501)
Cannot adjust printhead.
Cause Corrective Action
The Printhead nozzles are clogged. Follow the steps below to check the nozzles.
1. Print a test pattern to check the nozzles.
( → P .516)
2. Clean the Printhead if the nozzles are clogged.
( → P .517)
Highly transparent lm is loaded that cannot be used
for Printhead adjustment.
W e recommend using a type of paper that you often
use, other than lm, for Printhead adjustment.
( → P .491)
Error Message 587

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
