Control Panel
Main Menu Settings
Main menu items are described in the following tables.
For instructions on selecting or setting menu items, see “Main Menu Operations”. (→P .33)
For details on menu levels and values, see “Menu Structure”. (→P .37)
Setting Item
Description, Instructions
Paper Cutting This command is available only if a roll is loaded.
Choose Y es to cut the roll at the current position. However , if paper cannot be
advanced to the cut position, it will not be cut. In this case, manually advance
the roll before cutting it. ( → P .1 18)
Rep. Ink T ank When replacing ink tanks, choose Y es and follow the instructions on the screen.
( → P .508)
Head Cleaning Clean the Printhead . ( → P .517)
Choose Head Cleaning A if printing is faint, oddly colored, or contains foreign
substances.
Choose Head Cleaning B if no ink is printed at all, or if printing is not improved
by Head Cleaning A .
Media Menu Specify the type and size of paper . ( → P .51)
Paper Details Specify detailed paper-related settings, including the ink drying time and
borderless printing options. ( → P .52)
Job Management Manage print jobs on the printer ’ s hard disk. ( → P .54)
GL2 Settings Specify settings for HP-GL/2 printing. ( → P .55)
Adjust Printer Adjust the Printhead alignment or amount of feed by printing a test pattern.
( → P .57)
Interface Setup Congure the EOP timer and network settings. ( → P .58)
Maintenance Access maintenance settings when replacing the Printhead or preparing to move
the printer . ( → P .59)
System Setup Specify the printer system settings, including the date format and display
language. ( → P .59)
T est Print Choose Status Print to print information about the printer .
Choose Media Details to print the paper settings as specied in Paper Details .
Choose Print Job Log to print a record of print jobs, including the paper type
and size, amount of ink used, and so on. (Information on ink consumption is
general, not specic in nature.)
Choose Menu Map to print a list of the main menu options.
Choose Nozzle Check to print a test pattern for checking the nozzles.
Information Displays printer information and a record of print jobs. ( → P .61)
50 Printer Parts

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
