Canon imagePROGRAF IPF720 User Manual

Handling sheets
Handling sheets
Selecting the Paper Source
When advancing paper , press the Feeder Selection button and select the source.
Y ou can determine the selected source by checking which lamp is lit-either the Roll Media lamp (a) or the
Cut Sheet lamp (b).
• Roll Media lamp : Selected when printing on Roll Media .
• Cut Sheet lamp : Selected when printing on Sheets .
Note
• If any paper is loaded that will not be used, a message is shown on the Display Screen , either Remove
roll? or Eject sheet? when you press the Feeder Selection button.
When removing the paper , press the OK button.
• Y ou cannot switch the paper source in the following situations:
• If the Message lamp is ashing
Check the message on the Display Screen and take action as necessary . ( → P .575)
• If the Data lamp is ashing
Select the paper source after printing.
• If a printer menu operation is in progress
Select the paper source after the menu operation.
• When in the process of loading paper
Finish loading the paper before selecting the paper source.
• When in the process of replacing Ink T anks
Finish replacing the Ink T anks before selecting the paper source.
• If the T op Cover is open
Close the T op Cover before selecting the paper source.
Handling Paper 131

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
