Canon imagePROGRAF IPF720 User Manual

Hard Disk
Erasing Data on the Printer ’ s Hard Disk
Y ou can erase data on the printer ’ s hard disk from the Control Panel .
There are three ways to erase the data, as follows.
Erasure Method
T ime Required
Details
High Speed A few seconds Erases le management data for print job data stored on the
printer ’ s hard disk. Choose this method for relatively fast
erasure. Because only the le management data is erased, the
print job data itself is not erased. Note that it may be possible to
read this data using commercial data recovery software.
Secure High Spd. About 40 minutes Overwrites the entire hard disk with random data. No verication
is performed to check if the data was correctly written. Choose
this method to erase highly condential data. Note that it may
be possible to read the overwritten data using specialized data
recovery tools.
Secure About 20 hours Overwrites the entire hard disk with 00, FF , and random data
(one time each). V erication is performed to check if the data
was correctly written. Choose this method to erase especially
condential data. It is virtually impossible to recover the
overwritten data. Conforms to the DoD5220.22-M standard of
the U.S. Department of Defense.
Note
• For a more secure method of preventing data recovery , we recommend physically or magnetically
destroying the hard disk. In this case, the hard disk can no longer be used.
• Erase HDD Data is not available if there is a job queue.
Also note that during execution of Erase HDD Data , print jobs cannot be processed.
1. Press the Menu button to display MAIN MENU .
2. Press ▲ or ▼ to select System Setup , and then press the ► button.
3. Press ▲ or ▼ to select Erase HDD Data , and then press the ► button.
4. Press ▲ or ▼ to select the method of erasure, and then press the ► button.
5. Press ▲ or ▼ to select Y es , and then press the OK button to display the conrmation screen.
6. Press ▲ or ▼ to select Y es , and then press the OK button to start erasure.
490 Hard Disk

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
