Canon imagePROGRAF IPF720 User Manual

Messages regarding printheads
Messages regarding printheads
Cannot adjust printhead.
Cause Corrective Action
The Printhead nozzles are clogged. Follow the steps below to check the nozzles.
1. Print a test pattern to check the nozzles.
( → P .516)
2. Clean the Printhead if the nozzles are clogged.
( → P .517)
Highly transparent lm is loaded that cannot be used
for Printhead adjustment.
W e recommend using a type of paper that you often
use, other than lm, for Printhead adjustment.
( → P .491)
Cannot adjust band.
Cause Corrective Action
The Printhead nozzles are clogged. Follow the steps below to check the nozzles.
1. Print a test pattern to check the nozzles.
( → P .516)
2. Clean the Printhead if the nozzles are clogged.
( → P .517)
Highly transparent lm is loaded that cannot be used
for feed amount adjustment.
Adjust the feed amount manually .
( → P .501)
PHead needs cleaning.
Cause Corrective Action
The Printhead nozzles are clogged. Specify Printhead cleaning options.
( → P .517)
If the message is still displayed after Head Cleaning
B , contact the Canon dealer for assistance.
Problem with Printhead
Cause Corrective Action
The Printhead nozzles are becoming clogged. If printing is faint, clean the Printhead .
( → P .517)
588 Error Message

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
