Network Setting (Windows)
Specifying NetW are Protocols
Follow the steps below to congure NetW are protocol settings other than the frame type by using RemoteUI .
Note
• For details on RemoteUI , see “Using RemoteUI”. (→P .407)
1. Start the web browser and enter the following URL in the Location (or Address ) box to display
the RemoteUI page.
http:// “printer IP address or name” /
Example: http://xxx.xxx.xxx.xxx/
2. Select Administrator Mode and click Logon .
3. If a password has been set on the printer , enter the password.
4. Click Network in the Device Manager menu at left to display the Network page.
5. Click Edit in the upper-right corner of the NetW are group to display the Edit NetW are Protocol
Settings page.
6. Make sure the Frame T ype indicates the frame type used on the NetW are network.
7. T o use burst mode, choose On for NCP Burst Mode .
Note
• Burst mode supports fast data transfer when printing in queue server mode. Normally , choose On .
8. In Print Application , click the print service to be used.
Note
• Only one print service selected here will be enabled. Multiple print services are not available at
the same time.
9. For packet signature, click If Requested by Server in Packet Signature .
10. Complete the following settings based on the selected service.
• If you have selected Bindery PServer: Queue Server Mode (Using a Bindery Print Server)
1. In File Server Name , enter the le server name.
2. In Print Server Name , enter the name of the print server created in " Specifying NetW are
Print Services . (→P .424)"
3. In Print Server Password , enter the password of the print server created in " Specifying
NetW are Print Services . (→P .424)"
4. In Polling Interval , specify the interval at which the printer checks the NetW are print queue.
• If you have selected RPrinter: Remote Printer Mode (Using a Bindery Print Server)
1. In Print Server Name , enter the advertising name of the print server created in " Specifying
NetW are Print Services . (→P .424)"
2. In Printer Number , enter the same printer number specied in " Specifying NetW are Print
Services . (→P .424)"
Network Setting 427

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
