Canon imagePROGRAF IPF720 User Manual

Printer Driver
Accessing the Printer Driver Dialog Box from
Applications (W indows)
1. Choose Print from the File menu to display the dialog box for printing conditions.
2. Select the printer , and then display the printer driver dialog box.
Note
• The dialog box for specifying printing conditions varies depending on the source application. In some
cases, when you select the printer , a sheet for conguring the printer driver is added to the dialog box.
In the following case, click Preferences .
■Example: Print dialog box displayed by the application software
Six sheets of print settings are displayed by the printer driver: Main , Page Setup , Layout ,
Favorites , Utility , and Support .
Note
• The titles of dialog boxes may vary depending on the application, and sheets other than these
six sheets may be displayed.
Windows Software 343

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
