Canon imagePROGRAF IPF720 User Manual

Handling rolls
Removing Rolls From the Roll Holder Slot
Remove rolls from the Roll Holder Slot as follows.
Make sure the roll is away from the Paper Feed Slot , and then remove the Roll Holder from the Roll Holder Slot .
Removing a Roll from the Roll Holder
1. Lift the Holder Stopper lever (a) from the shaft side to unlock it. Holding the Holder Stopper at
the position indicated (b), remove it from the Roll Holder .
2. Remove the roll from the Roll Holder .
Important
• After removal, store the roll in the original bag or box, away from high temperature, humidity , and
direct sunlight. If paper is not stored properly , the printing surface may become scratched, which
may af fect the printing quality when you use it again.
1 14 Handling Paper

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
