Canon imagePROGRAF IPF720 User Manual

Adjusting the feed amount
Adjusting the Measurement Scale for Better Accuracy
T o adjust the measurement scale and ensure accuracy (so that lines in CAD drawings are printed at exactly
the right length, for example), specify the amount of paper stretching or shrinkage when adjusting the feed
amount.
Note
• If printed images are af fected by banding in dif ferent colors, adjust the amount that paper is fed.
( → P .501)
Important
• Use paper of the same type and size for adjustment as you will use for printing.
• T o apply the results of adjusting the measurement scale for better accuracy in printing, you must rst set
Feed Priority to Print Length . Note that if you select Automatic , the results of adjustment will only be
applied in printing if you set Print Priority in the printer driver to Line Drawing/T ext . ( → P .180)
Follow these steps to change the Feed Priority setting.
1. Press the Menu button to display MAIN MENU .
2. Press ▲ or ▼ to select Paper Details , and then press the ► button.
3. Press ▲ or ▼ to select the type of paper , and then press the ► button.
4. Press ▲ or ▼ to select Feed Priority , and then press the ► button.
5. Press ▲ or ▼ to select Print Length or Automatic , and then press the OK button.
Follow these steps to adjust the scale for better accuracy .
1. When using sheets, load one unused sheet A4/Letter-sized or larger .
When using a roll, load a roll 10 inches (254 mm) or wider .
• Loading the Sheet in the Printer (→P .133)
• Loading Rolls on the Roll Holder (→P .107)
• Loading Rolls in the Roll Holder Slot (→P .109)
• Loading the Roll in the Printer (→P .1 10)
Note
• When loading paper , specify the correct paper type. When the paper type is not specied, the
printing quality may be af fected without the correct adjustment of the feeding.
• W e recommend using the type of paper you use most often for feed amount adjustment.
504 Adjustments for Better Print Quality

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
