Canon imagePROGRAF IPF720 User Manual

Hard Disk
Moving saved jobs
Print jobs for which Print is selected as the format in Output Method (in Windows) or Send job to (in Mac OS X)
are saved in the Common Box, number “00” . However , jobs in this mail box will be deleted one after another
starting with the oldest job in the following situations.
• If there are more than 100 saved jobs in the Common Box and job queue combined
• If the temporary storage area becomes full during reception of print jobs for which you have selected
Print or Print (auto delete) in Output Method (in Windows) or Send job to (in Mac OS X)
• If the temporary and permanent storage areas no longer have enough space during reception of print
jobs for which you have selected Save in mail box in Output Method (in Windows) or Send job
to (in Mac OS X)
Y ou can move jobs to Personal Boxes “01” to “09” to prevent them from being deleted. (Up to 100 jobs can
be stored here.)
Y ou can also move saved jobs from one Personal Box to another .
Y ou can move stored print jobs as follows.
• Using RemoteUI
• Using imagePROGRAF Status Monitor (Windows)
• Using imagePROGRAF Printmonitor (Macintosh)
Note
• Jobs saved in Personal Boxes cannot be moved to the Common Box.
Using RemoteUI
1. On the Stored Job page, choose the mail box.
470 Hard Disk

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
