Canon imagePROGRAF IPF720 User Manual

Cutter Unit
Replacing the Cutter Unit
Note
• For information on compatible Cutter Unit , see “Cutter Unit”. (→P .525)
• During Cutter Unit replacement, do not open the Carriage Cover . Ink will automatically ll the Printhead
after the Carriage Cover is opened, which consumes ink.
1. T urn the printer on. ( → P .22)
2. Press the Menu button to display MAIN MENU .
3. Select Maintenance → Change Cutter → Y es , and then press the OK button.
After the Carriage is centered, a message is shown on the Display Screen instructing you to
open the T op Cover .
Note
• If you do not respond within two minutes, cutter replacement is canceled and the printer goes online
automatically . In this case, repeat the steps above.
4. Open the T op Cover .
5. If the Cutter Unit or Carriage is dirty , use a damp cloth that you have wrung out completely
to wipe it clean.
Important
• Do not touch the Linear Scale (a) or Carriage Shaft (b).
526 Maintenance

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
