Canon imagePROGRAF IPF720 User Manual

Printer Driver
V iew Settings Dialog Box for the Printing Application
(W indows)
In the V iew Settings dialog box, you can check details of the selected printing application.
Note
• T o display the V iew Settings dialog box, on the Main sheet, click V iew Settings by Print T arget .
( → P .347)
Setting Item Description
A Print T arget
Shows all Print T arget options (settings items for the printing application).
B Name Identies the item selected in Print T arget by its name and an icon.
C Details
Here, you can conrm detailed settings values for each listed item for the
selected Print T arget .
352 Windows Software

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
