Canon imagePROGRAF IPF720 User Manual

Handling rolls
Detection of the Remaining Roll Paper
If you have activated automatic detection of the remaining roll paper , when the roll is ejected, a barcode with text is
printed on the roll paper that identies the type of paper and amount left. If this function is activated and barcodes
are printed on the roll paper , the type of paper and amount left are automatically detected when you load a
roll. The barcode will be cut of f after it has been read.
Note
• If the document is not cut but kept in the printer , only the text message is printed. This is also the
case when printing on 8-inch rolls or clear lm.
Important
• If the barcode is not detected when it is advanced, enter the type and length of paper on the Control
Panel.
• Barcodes are not cut of f when Chk Remain.Roll and T rim Edge First are both Off . T o have the printer
cut of f barcodes automatically , on the Control Panel menu, set Chk Remain.Roll to On . Otherwise cut
of f barcodes by using Paper Cutting in the Control Panel menu.
Follow these steps to activate detection of the remaining roll paper .
1. Press the Menu button to display MAIN MENU .
2. Press ▲ or ▼ to select Media Menu , and then press the ► button.
3. Press ▲ or ▼ to select Chk Remain.Roll , and then press the ► button.
4. Press ▲ or ▼ to select the desired setting option, and then press the OK button.
Handling Paper 1 19

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
