Canon imagePROGRAF IPF720 User Manual

Printer Driver
Main Sheet (W indows)
The following settings are available on the Main sheet. For details on settings items, refer to the printer
driver help le.
Note
• On the Main sheet, choose Easy Settings to specify basic print settings based on the particular printing
application, or switch to Advanced Settings to complete more detailed settings as desired.
Conguration using Easy Settings
Setting Item Description
A Media T ype
Select the type of paper .
For information on the types of paper the printer supports, refer to the Paper
Reference Guide . ( → P .96)
B Get Information Click to display the Paper Information on Printer dialog box, which shows
the types and sizes of paper specied on the printer for each feed source.
When you select a feed source, your selection is applied to the printer driver
settings for the feed source, type of paper , and roll width.
C Advanced Settings
Click to display the Paper Detailed Settings dialog box for ink drying time
and other detailed settings based on the type of paper .
E Print T arget Choose presets that match the type of document to be printed.
Printing Photos and Images (Windows, Mac OS X) (→P .144)
Printing Line Drawings and T ext (Windows, Mac OS X) (→P .153)
Printing Of ce Documents (→P .163)
Depending on the Media T ype setting, some Print T arget options may
not be available.
F V iew Settings Click to display the V iew Settings dialog box, which enables you to conrm
the settings for the selected item from the E Print T arget list or change the
order of items listed in E Print T arget .
L Open Preview When Print
Job Starts
Activate this option to check on-screen previews of documents before
printing.
Checking the Layout in a Preview Before Printing (→P .31 1)
Windows Software 347

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
