Canon imagePROGRAF IPF720 User Manual

Printer Driver
Special Settings Dialog Box (W indows)
If the printing results are not as you expected, you can change how printing is processed in the Special
Settings dialog box.
Note
• T o display the Special Settings dialog box, on the Layout sheet, click Special Settings . ( → P .362)
Setting Item Description
A FineZoom Settings
This function is used in large-format printing. Normally , choose Auto . If
documents are not printed correctly on large-format paper , it may help to
select Y es , and if ne lines are not visible or if images are distorted when
printed, it may help to select No .
B Application Color Matching
Priority
Y ou can give applications priority in color management.
C Enable Preview Switching
Selecting this option will start PageComposer if you print when Open
Preview When Print Job Starts is selected on the Main sheet.
D Fast Graphic Process If image colors are inconsistent in printed documents or if lines are printed
in varying thicknesses, clearing this option may help produce the expected
results.
E Reduce Print Unevenness If you are concerned about uneven colors, selecting this option may
improve printing results. However , printing may take longer for some
images.
F Adjust faint lines If ne lines are printed in colors that do not match the colors of other
shapes, clearing this option may help produce the expected results.
However , lines in some colors may appear broken.
Windows Software 365

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
