Canon imagePROGRAF IPF720 User Manual

Network Setting
Using RemoteUI
Enter the printer ’ s IP address in a web browser to display the RemoteUI page. After you log on to RemoteUI from
the page, you can check and change the status of the printer and print jobs, and congure network settings.
T o access RemoteUI , start the web browser and enter the following URL in the Location (or Address ) box to
display the RemoteUI page.
http:// “printer IP address or name” /
Example: http://xxx.xxx.xxx.xxx/
For details on conguring printer settings for networks, refer to the following topics.
• Conguring the Printer ’ s TCP/IP Network Settings (→P .408)
• Conguring the Printer ’ s AppleT alk Network Settings (→P .410)
• Conguring the Printer ’ s NetW are Network Settings (→P .41 1)
• Specifying Printer-Related Information (→P .413)
Note
• RemoteUI also of fers many other features. Y ou can display the ink levels, check error messages and
other status information, and cancel print jobs.
• By factory default, the English screen is displayed. T o change the display language, select the desired
language under Language before logging on in administrator mode.
Important
• Use Netscape Navigator 6.0 or later , Internet Explorer 5.01 or later , or Firefox 1.5 or later as a web
browser . In Mac OS X, you can also use Safari 1.32 or later or Safari 2.03 or later .
• Access is not possible via a proxy server . In environments where a proxy server is used, add the
printer ’ s IP address to Exceptions (addresses accessed without a proxy server) in the web browser
proxy server settings. (Settings may vary depending on the network environment.)
• Enable JavaScript and cookies in the web browser .
• If you access RemoteUI with the printer name instead of its IP address, make sure the DNS settings are
correctly congured.
Network Setting 407

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
