Canon imagePROGRAF IPF720 User Manual

Handling rolls
Removing the Roll from the Printer
Remove rolls from the printer as follows.
Note
• If you need to cut a printed roll, select Paper Cutting in the printer menu and cut the roll at the desired
position. ( → P .122)
• If you have selected Media Menu > Chk Remain.Roll > On in the printer menu, a barcode indicating
the amount of paper left is printed on the leading edge of the roll. However , barcodes are not printed on
some types of paper , and only a text message indicating media information is printed.
Caution
• If you have activated automatic monitoring of the remaining roll paper , do not remove the roll before the
barcode is printed. Y ou will be unable to keep track of the amount of roll paper left.
1. Press the Load/Eject button.
A conrmation message is displayed regarding removal of the roll.
2. Press the OK button.
The roll can now be removed.
Next, when removing rolls from the Roll Holder Slot , see “Removing Rolls From the Roll Holder
Slot”. (→P .1 14)
Handling Paper 1 13

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
