Canon imagePROGRAF IPF720 User Manual

Messages regarding paper
Roll printing is selected.
Cause Corrective Action
Load a roll and try printing again.Y ou have attempted to print a test print sheet or
other printer status information on a roll, but no roll
is loaded.
T o print on a sheet instead, hold the Stop button for
more than a second to cancel printing, load a sheet,
and then print.
( → P .86)
Roll printing is selected, but sheets are loaded.
Cause Corrective Action
Press the OK button and remove the sheet.
( → P .137)
Load a roll and try printing again.
( → P .1 10)
A print job for rolls was received when a sheet is
loaded.
Hold down the Stop button for a second or more to
cancel printing.
The roll is empty .
Cause Corrective Action
There is no more paper left on the roll. Follow the steps below to replace the used roll with a
new roll of the same type and size.
1. Remove the roll.
( → P .1 13)
( → P .1 14)
( → P .1 14)
2. Load the new roll.
( → P .107)
( → P .109)
( → P .1 10)
3. If no barcode was printed on the roll, specify the
paper type.
( → P .105)
4. If no barcode was printed on the roll, specify the
paper length.
( → P .106)
580 Error Message

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
