Canon imagePROGRAF IPF720 User Manual

Network Setting (Mac OS X)
Conguring the Destination for AppleT alk Network
(Macintosh)
T o print over an AppleT alk network, activate the AppleT alk protocol and congure the destination as follows.
Activating AppleT alk on the printer
Important
• By factory default, the AppleT alk protocol is disabled on the printer .
1. Press the Menu button to display MAIN MENU .
2. Press ▲ or ▼ to select Interface Setup , and then press the ► button.
3. Press ▲ or ▼ to select AppleT alk , and then press the ► button.
4. Press ▲ or ▼ to select On , and then press the OK button.
5. Press the Online button to bring the printer online.
If any of the settings is changed, a message for conrmation is displayed. In this case, press
the OK button.
Important
• Be sure to complete step 5. This will activate the values you have entered.
Note
• By using RemoteUI , you can also specify the object name used by AppleT alk, as well as the printer
zone name.
For details on RemoteUI , see “Using RemoteUI”. (→P .407)
Network Setting 433

Canon imagePROGRAF IPF720 Specifications

Operating Environment

temperature range	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)
acoustic noise operation	52dB (A) or Less

Print Specifications

print resolution max	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm

Ink and Print-Head

number of nozzles matte black	5, 120 Nozzles
number of nozzles other colors	2, 560 Nozzles per Color
droplet size	4 Picoliter

Media Handling

media width roll feed	10" – 36" (254mm – 914.4mm)
cut sheet width	8" – 36" (203.2mm – 914.4mm)
maximum print length roll feed	59' (18m)

Power

power supply	AC 100–240V (50-60Hz)
power consumption maximum	140W or Less
power off consumption	1W or Less

Weight and Dimensions

printer dimensions	43.1" x 59.3" x 34.3"
dimensions in mm	1507mm x 871mm x 1094mm
weight with stand	Approx. 141 lb (64kg)
